XPS-DR Power Supply

$6,595.00

The XPS is a simple and effective upgrade to enhance the music-making ability of your Naim Audio source component. It can be used to upgrade the CDX2 CD player and DAC digital to analogue converter, and it is also suitable for use with the NDS, NDX and ND5 XS network players and HDXhard-disk player/server. Its large toroidal transformer features six separately regulated, low-noise outputs and benefits from Naim Audio DR voltage regulator technology.

Click to email your order

SKU: NAXPSDR Categories: ,

Product Description

Upgrade Your Music

The XPS is a simple and effective upgrade to enhance the music-making ability of your Naim Audio source component. It can be used to upgrade the CDX2 CD player and DAC digital to analogue converter, and it is also suitable for use with the NDS, NDX and ND5 XS network players and HDXhard-disk player/server. Its large toroidal transformer features six separately regulated, low-noise outputs and benefits from Naim Audio DR voltage regulator technology.

Features
  • Six separately regulated low-noise outputs plus six power regulators
  • All-new Discrete Regulator (DR) configuration, delivering Naim Audio’s best-ever standards of stable, low-noise power
  • Brushed, black-anodised aluminium chassis plus anti-vibration feet
Technology & Craft

The Naim Audio XPS is a highly sophisticated power supply with six separately regulated, very low noise outputs, featuring a toroidal transformer and six power regulators. These supplies are branched and re-regulated, some twice in the CD player.

The addition of anti-vibration, resonance-controlling feet complement the elegant cast and extruded anti-magnetic chassis protect the sensitive internal components from resonance and microphonic vibration.

The XPS was updated in 2012 as a result of a two year project to develop a new discrete regulator (DR) for Naim Audio power supplies. The new Naim Audio DR now features, alongside improvements to the mechanical decoupling and internal layout. These enhancements, developed through intensive listening tests, significantly raise performance and make music even more communicative and enjoyable.

Please note: only new classic series XPS units are compatible with the NDX network player, not ‘Olive’ versions. The old ‘Olive’ XPS is still compatible with CDX and CDS model CD players, the HDX hard disk player and the DAC digital to analogue converter however. Please contact us if you are unsure of compatibility.

Outputs
Power Outputs ± 22V, ± 10V, 2 x 15V
Upgrades
Other Power-Line
Power
Mains Supply 100V, 115V, 230V; 50 or 60Hz
Physical
Dimensions (HxWxD) 87 x 432 x 314mm
Weight 12.4 kg
Shipping Dimensions 240 x 590 x 500mm
Shipping Weight 15.1 kg
Supplied with Burndy
Finish
Front Brushed and black anodised
Case Black powder coated
