SuperCap-DR Power Supply Ex Demo

$8,599.00 $6,000.00

As iconic as it is widely acclaimed, the SuperCap is a Naim Audio classic, capable of powering every preamplifier in the Naim range except for the NAC-N 172 XS and the NAC 552. Its substantial toroidal transformer and high-quality smoothing capacitors combine to ensure improved timing, clarity and dynamic range from your favourite music.

Upgraded with our new DR voltage regulator, this timeless component remains one of the most well know and oft-employed power supplies in the Naim range.

Click to email your order

SKU: NASCAPDR Categories: ,

Product Description

Powerful and Versatile

As iconic as it is widely acclaimed, the SuperCap is a Naim Audio classic, capable of powering every preamplifier in the Naim range except for the NAC-N 172 XS and the NAC 552. Its substantial toroidal transformer and high-quality smoothing capacitors combine to ensure improved timing, clarity and dynamic range from your favourite music.

Upgraded with our new DR voltage regulator, this timeless component remains one of the most well know and oft-employed power supplies in the Naim range.

Features
  • 13 x 24V outputs, 2 x 12V output
  • All-new Discrete Regulator (DR) configuration, delivering Naim Audio’s best-ever standards of stable, low-noise power
  • Brushed, black-anodised aluminium chassis
Technology & Craft

Each of the multiple power outputs on the SuperCap uses Naim Audio’s specially designed discrete regulators for optimum performance. The SuperCap can be used to power all of the Naim Audio preamplifier (except the NAC 552 and NAC-N 172 XS), Superline phono stage and active crossovers, and is the only choice for supplying power to the NAC 252 preamplifier.

Its anti-vibration, resonance-controlling feet complement the elegant new cast and extruded anti-magnetic chassis to protect the sensitive internal components from resonance and microphonic vibration.

The SuperCap was updated in 2012 as a result of a two year project to develop a new discrete regulator (DR) for Naim Audio power supplies. The new Naim Audio DR now features, alongside improvements to the wire routing, mechanical decoupling and internal layout. These enhancements, developed through intensive listening tests, significantly raise performance and make music even more communicative and enjoyable.

Outputs
Power Outputs 13 x 24V, 2 x 12V
Upgrades
Other Power-Line
Power
Mains Supply 100V, 115V, 230V; 50 or 60Hz
Physical
Dimensions (HxWxD) 87 x 432 x 314 mm
Weight 11.6 kg
Shipping Dimensions 240 x 590 x 500 mm
Shipping Weight 14.2 kg
Finish
Front Brushed and black anodised
Case Black powder coated
